1960 Porsche 718 RS60 Spyder

Despite being made for the small engine displacement classes, Porsche nearly won the 1960 Manufacturers Championship with the RS 60. These purposeful racers featured 1.5, 1.6 or 1.7 liter engines in a low and lightweight chassis. They always won the 1.6 liter class, but typically raced in and among the 3.0 liter Ferraris.

Porsches mid-engine racecars started with the 550 RS which was replaced by the lower 718 RSK and updated in 1960 to meet new regulations. This new version, called the 718 RS 60, met FIA-imposed rules which mandated larger interior spaces, taller windshield heights and larger door sizes.

To comply, Baron Huschke von Hanstein reluctantly updated the factory-raced 718 RSK. It was necessary to increase the length and width of the tubular steel chassis to accommodate minimum sizes for the interior. This made the RSK instantly redundant and von Hanstein’s team had only six months to prepare.

The new car used the very latest double wishbone rear suspension which was on some of the very last RSKs. Both the engine and transmission remained virtually unchanged. Options included the 166 bhp Type 547/3 1498cc engine or the more popular 178 bhp Type 547/4 1587cc unit. Wheelbase was extended four inches so the car weighed more than its predecessor, but smaller diameter wheels and tires helped keep weight down.

After an immediate run of four cars specially prepared for the factory, Porsche made about twelve examples for private entrants. The car debuted at the Sebring 12 Hours in 1960 and won the race outright in the hands of Hans Herrmann and Olivier Gendebien. For the Targa Florio, three cars were prepared including two with new Type 547/5 1679cc engines. Driven by Jo Bonnier and Hans Herrmann, one of these finished first overall and it was the car’s best ever achievement.

The rest of the season was remarkable. Jo Bonnier and Olivier Gendebien finished second overall at the Nurburgring and put Porsche at the top of the Manufacturer’s championship. LeMans was the breaking point. The mandated windscreens and small engines did couldn’t cope with the very fast track. In the end, Porsche tied Ferrari for the season which was remarkable since Ferrari was racing 3.0 liter cars. The FIA gave the year to Ferrari and this narrow defeat wasn’t avenged until 1969.

After a successful year, Porsche continued to offer the RS 60 and changed its name to the RS 61. Completely identical in specification to the RS 60, it raced alongside the W-RS which had a more extended nose. In 1963, the factory released detailed documents on how to upgrade the Type 547/4 and Type 547/5 and gain an increase of about 10 bhp.

In Detail

submitted by Richard Owen
type Racing Car
built at Germany
predeccesor 1957 Porsche 718 RSK Spyder
succeccesor 1961 Porsche 718 RS61 Spyder
engine Type 547/4 Flat-4
position Mid, Longitudinal
aspiration Natural
valvetrain DOHC, 2 Valves per Cyl
fuel feed Twin Weber 46 IDM1 Carburetors
displacement 1587 cc / 96.8 in³
compression 9.8:1
power 111.9 kw / 150 bhp @ 7800 rpm
specific output 94.52 bhp per litre
bhp/weight 258.18 bhp per tonne
torque -1.0 nm / -1.0 ft lbs @ 8000 rpm
body / frame Aluminum Body over Steel Spaceframe
driven wheels RWD
front tires 5.5×15
rear tires 6.00×15
front brakes Magnesium Drums
rear brakes Magnesium Drums
front wheels F 38.1 x 10.2 cm / 15 x 4 in
rear wheels R 38.1 x 10.2 cm / 15 x 4 in
steering Worm & Nut
f suspension Trailing Arms w/Koni Shock Absorbers, Coil Springs
r suspension Double Wishbones w/Koni Shock Absorbers, Coil Springs
curb weight 581 kg / 1280 lbs
wheelbase 2200 mm / 86.6 in
front track 1290 mm / 50.8 in
rear track 1250 mm / 49.2 in
length 3700 mm / 145.7 in
transmission 5-Speed Manual
top speed ~230 kph / 142.9 mph
key drivers Graham Hill, Jo Bonnier, Hans Herrmann
race victories 1960 Sebring 12 Hours 1OA, 1960 Targa Florio 1OA

Auction Sales History

1960 Porsche 718 RS60 Spyder

1960 Porsche RS60 718-044 – sold for $5,400,000 The Ultimate Development of Porsche’s Four-Cam Spyder. The Last of Only Four Works RS60s Ever Built. Porsche Factory Entry in Important FIA World Championship Races. Raced by Moss, Hill, Barth, Herrmann, Gurney, and Holbert. One of the Most Significant Porsche Spyders in Private Hands. Auction Source: The Pebble Beach Auctions 2015 by Gooding and Company

1960 Porsche 718 RS60 Spyder

1960 Porsche RS60 718-060 – sold for $3,465,000. The Ultimate Development of Porsche’s Four-Cam Spyder. One of Only 14 Customer RS60s Built. Illustrious Racing Record with 12 Class Wins in Just Four Seasons. Driven at Elkhart Lake, Meadowdale and Watkins Glen. Well-Documented History with Outstanding Provenance. Matching-Numbers, Original-Bodied Example. Monterey Historics and Rennsport Reunion Participant. Displayed at Meadowbrook, The Quail and the Porsche Race Car Classic. One of the Finest RS Spyders in Existence. Auction Source: 2012 Pebble Beach Auctions by Gooding & Company
