In 1913, Mercedes updated their mid-range 7.2-liter cars to have 60 HP at 1300rpm. These were the largest cars to use a drive shaft system as the 9.0-liter flagship models were all chain-driven.

The 28/60 PS was included with the โ€œcardan carsโ€ that were named in honor of Gerolamo Cardano’s theories and the universal joint which made the drive shaft possible.

Also known as the 60HP, the 28/60 PS was a mid-range Mercedes that was only one step below the flagship 9.0-liter, 6-cylinder cars. Many were used by dignitaries and the model was regarded with high esteem after Mercedes won the French Grand Prix.

Some 7.2-liter cars were ordered on occasion with with chain-drive if the car was going to subject to rougher roads.

In Detail

tags 60hp
submitted by Official Galleries
type Series Production Car
engine Inline-4
position Front, Longitudinal
block material Cast Iron
valvetrain Side Valves
displacement 7240 cc / 441.81 inยณ
power 37.3 kw / 50 bhp @ 1200 rpm
specific output 6.91 bhp per litre
body / frame Body over Steel Chassis
driven wheels RWD
front brakes None
f suspension Rigid Axle w/Semi-Elliptic Leaf Springs
r suspension Live Axle w/Semi-Elliptic Leaf Springs
wheelbase 135 mm / 5.3 in
transmission 4-Speed Manual
