1934→1938 Mercedes-Benz 540 K Autobahnkurier
Autobahnkurier 3_4 Front Hintergrund 001

1934→1938 Mercedes-Benz 540 K Autobahnkurier

1934→1938 Mercedes-Benz 540 K Autobahnkurier

Some production cars have become iconic, but it takes higher level of distinction to have a single car create equal impact. Such is the case with this Autobahnkurier that was named after the new highways in and around Berlin. Supposedly, when Jean Bugatti first laid eyes on this streamlined fastback he went back home and designed the famed Atlantic.

There’s good reason why the Autobahnkurier caused a sensation. It’s long hood, sweeping lines and refined elegance were little matched. And when combined with one of the best pre-war chassis, it was also hard to ignore. To maintain brand recognition Mercedes-Benz insisted that this fastback retain the standard front radiator. It also featured the first Mercedes-Benz curved rear-quarter windows.

Prototype

Mercedes-Benz released the prototype in February of 1934 at the Berlin Motor Show. This specific car started out as a 500K chassis with a covered front bumper and covered wire-wheels. Known as chassis number 130898, it was gifted to Mohammed Reza Shah of Iran by the German government and spent most of it’s life in Iran.

The car was eventually owned by Julian Mazjub who said “although listed as a 500K, the car had a 5.4 liter engine”.¹ When found by an Mercedes-Benz Truck importer in the 1960s, the car was totally original with only 10,000 km on the odometer. At this time it’s two-tone green paint was noted as was its enclosed bumper.¹

Second Car

A second car was built and based off the original Berlin prototype. It was listed as order number 288557 and completed in 1938 for professor Ingacio Barraquer. He was in Germany on vacation from his regular residence in Spain. Barraquer used this car often and went on many long journeys including a famous drive through North Africa. He traveled from Libya, Cairo then finished in Alexandria before the car was shipped back. Along the way he had to fix a shredded tire, worn dampers and a head gasket.

In the 1950s, Barraquer found the car too difficult to maintain and replaced it with a more modern 300S. It was then given to his son-in-law and stayed in the family for decades. For some time it was loaned to Antic Car Club in Catalina who had it displayed in Barcelona.

Eventually, it was sold by the Barraquer family in 2004 and restored by Paul Russell & Co. before making a debut at the Pebble Beach Concours d’Elegance. It won the award for the most elegant coupe and was a runner up for Best in Show. This was followed up in 2008 by winning the Coppa d’Oro Villa d’Este.

Mercedes-Benz has reported that there might be a third car but this is unconfirmed as of June 2008.

Sources & Further Reading

1. Walsh, Mick. ‘Express Delivery’. Classic & Sports Car, May 2008.

Story by Richard Owen

In Detail

tags 540k
submitted by Richard Owen
type One Of
production years 1934 – 1938
released at 1934 Berlin
built at Stuttgart, Germany
coachbuilder Karosserie Sindelfingen
production 2
engine M 24 II, Inline-8
position Front, Longitudinal
aspiration Roots-Type Supercharger
block material Monobloc Cast Iron
valvetrain 2 Valves per Cyl
fuel feed Mercedes Updraught Carburettor
displacement 5401 cc / 329.6 in³
bore 88 mm / 3.46 in
stroke 111 mm / 4.37 in
compression 6.13:1
power 134.2 kw / 180 bhp @ 3400 rpm
specific output 33.33 bhp per litre
bhp/weight 71.94 bhp per tonne
body / frame Wooden Frame & Steel Panel Body over Pressed Steel Chassis
driven wheels RWD
front tires 7.0×17
rear tires 7.0×17
front brakes Lockheed Hydrualic Drums w/Vacuum Assist
rear brakes Lockheed Hydrualic Drums w/Vacuum Assist
front wheels F 43.2 x 10.2 cm / 17.0 x 4.0 in
rear wheels R 43.2 x 10.2 cm / 17.0 x 4.0 in
steering Worm & Nut
f suspension Double Wishbones w/Coil Springs, Hydraulic Shock Absorbers
r suspension Swing Axle w/Trailing Arms, Double Coil Springs, Hydraulic Shock Absorbers
curb weight 2502 kg / 5510 lbs
wheelbase 3290 mm / 129.5 in
front track 1535 mm / 60.4 in
rear track 1547 mm / 60.9 in
length 5258 mm / 207.0 in
width 1905 mm / 75.0 in
transmission 4-Speed Manual
gear ratios 3.90:1, 2.88:1, 1.45:1, 1.00:1
final drive 3.08:1
top speed ~185.03 kph / 115 mph
0 – 60 mph ~15.0 seconds
