1992 Vector WX3 Concept

1992 Vector WX3 Concept

1992 Vector WX3 Concept

The Vector A Avtech) WX-3 is a prototype automobile created by Vector Motors of Wilmington, California in 1992. Founder Gerald Wiegert planned for it to have a range of engines up to a 1000 hp (746 kW) 7.0L DOHC V8 motor, but the full series of engines was never completed. If the top-of-the-line engine had been completed, Vector projected that it could have been fine-tuned to reach speeds at over 250 mph (402 km/h). Instead, the AWX-3 used the same Rodeck resleevable turbocharged V8 from the W8.

The AWX-3 coupe was little more than a slightly updated rebodied W8, and could be considered Wiegert’s dream car. Wiegert planned for the AWX-3 to go in production, but Megatech hostilely took over Vector and fired Wiegert.

Wiegert initiated several lawsuits and copyrighted the designs, stamping out any hopes of the AWX-3 of going to production without his approval. Originally painted silver, the AWX-3 Coupe prototype was later re-painted in the teal color it bears today. It is powered by the same engine configuration as the W8 prototypes, a better flowing dual plenum and throttle-body intake tract rather than the ‘EPA friendly’ Corvette based system utilized on the W8 production cars.

At high boost levels it is capable of developing 1,200 hp. From the block to all of the internals, like every Vector of Weigert’s, it was built with the highest quality components available.

Vector WX3 Concept Images

In Detail

production 3
price $ $ Prototype
engine Twin Turbo Olds V8
displacement 7000 cc / 427.2 in³
power 745.7 kw / 1000 bhp @ 5800 rpm
specific output 142.86 bhp per litre
bhp/weight bhp per tonne
torque 950 nm / Not Available ft lbs @ 4900 rpm
driven wheels Mid Engine / RWD
front tires 245/40 ZR 16
rear tires 325/30 ZR 18
front brakes 13.5 in Vented Discs w/ABS
f brake size mm / in
rear brakes 13.5 in Vented Discs w/ABS
r brake size mm / in
curb weight 1620 kg / 3571 lbs
wheelbase 2616 mm / 103.0 in
length 4673 mm / 184.0 in
width 2032 mm / 80.0 in
height 1080 mm / 42.5 in
transmission 3-Speed Auto
gear ratios :1
top speed ~402.3 kph / 250.0 mph
