The Maserati 8CM was a Grand Prix race car produced by Maserati between 1933 and 1935. Maserati had designed two new engines (four cylinder and V8).

With advanced new engines added to a conventional steel ladder frame which was suspended all-round by solid axles and semi-elliptic leaf springs, the cars were strong performers. The four cylinder was fine, but the V8 caused flexing problems.

Maserati fixed the rigidity issues and and the modifications made a night and day difference. Tazio Nuvolari went from back of the grid to race winner with the changes in place.

See all our other Maserati Race Cars and full list of awesome Maserati cars and recent Maserati posts and news.

1933 Maserati 8CM Gallery

See all 1933 Maserati 8CM images

1933 Maserati 8CM In Detail

submitted by Richard Owen
engine Supercharged Inline-8
valvetrain DOHC 2 Valves / Cyl
displacement 2991 cc / 182.5 in³
bore 69 mm / 2.72 in
stroke 100 mm / 3.94 in
power 164.1 kw / 220 bhp @ 5500 rpm
specific output 73.55 bhp per litre
bhp/weight bhp per tonne
body / frame Aluminum
driven wheels Front Engine
front brakes Hydraulic Drums
f brake size mm / in
rear brakes Hydraulic Drums
r brake size mm / in
front wheels F 48.3 x 10.2 cm / 19 x 4 in
rear wheels R 48.3 x 11.4 cm / 19 x 4.5 in
steering Worm & Sector
curb weight 785 kg / 1730 lbs
wheelbase 2560 mm / 100.8 in
front track 1300 mm / 51.2 in
rear track 1300 mm / 51.2 in
length 3850 mm / 151.6 in
width 1570 mm / 61.8 in
height 1200 mm / 47.2 in
transmission 4-Speed Manual
gear ratios :1
top speed ~218.9 kph / 136 mph
