2014 Dodge SRT Viper GT3-R


2014 Dodge SRT Viper GT3-R
SRT Motorsports, 24 Hours of Le Mans, June 22-23, 2013, Viper GTS-R #93 driven by Jonathan Bomarito, Kuno Wittmer, and Tommy Kendall; Viper GTS-R #53 driven by Marc Goosens, Dominik Farnbacher, and Ryan Dalziel (Richard Prince/SRT Motorsports Photo).

2014 Dodge SRT Viper GT3-R

The SRT® Viper GT3-R is the direct descendent of the high performance GTS-R GTE class racer campaigned by SRT Motorsports in the 2013 24 Hours of Le Mans and the American Le Mans Series. Virtually all of the technology developed by the Chrysler Group for the factory GTS-Rs for engine, chassis, suspension, electronics and aerodynamics is infused into every Viper GT3-R. All of it. It’s your chance to get the knowledge of a factory race program in a 200 mph* striped package. The SRT Viper GT3-R builds upon the success of the GTS-R. The chassis has been equipped with a highly efficient aerodynamic package to optimize handling. Further racing enhancements include an Xtrac six-speed sequential transmission with paddle shifters, six-piston front brake calipers with four-piston rears, lightweight wheels and a multi-disc race clutch to help extract maximum performance from the V-10 engine.

Winning in motor racing is achieved through hard work, dedication and using the best tools available. The SRT® Viper GT3-R offers the chance to experience all of the Viper engineering and technology developed over years of international road racing. It offers a chance to be a part of the Viper legacy. The GT3-R is designed for the private racer who has the determination to win on an international level, but who desires to be competitive at a competitive price. In addition to eligibility for competition in GT3 championships worldwide, the GT3-R is ready for the United SportsCar Series GT Daytona, Pirelli World Challenge GT class, NARRA, SCCA and other GT categories. Pick your series, pick your goal, and get there with the SRT Viper GT3-R.

The Viper GT3-R is a collaborative race car created by SRT Motorsports and Riley Technologies in Mooresville, North Carolina. Riley Technologies specializes in the design, manufacture and support of winning race cars. Riley has built technologically advanced and dominant race cars from Daytona prototype endurance cars to GT competition cars. Their resume includes multiple U.S. endurance championships, race wins – including overall winner of the Rolex 24 Hours of Daytona the past nine years – and multiple GT championships.

Orders for the Viper GT3-R are now being taken for late 2013 delivery. Contact SRT Motorsports for more information and services, including trackside support.

Story by Chrysler Group LLC

In Detail

type Racing Car
released at 2013 24 Hours of Le Mans
built at USA
price $ $ 459,000
engine 90º V10
position Front, Logitunal
aspiration Natural
block material Aluminum Alloy
valvetrain Pushrod OHV, 2 Valves per Cyl w/VVT
fuel feed Multi-Port Electronic Injection
displacement 8383 cc / 511.56 in³
bore 103.0 mm / 4.055 in
stroke 100.6 mm / 3.96 in
power 507.1 kw / 680 bhp @ 6200 rpm
specific output 81.12 bhp per litre
torque 867.7 nm / 640 ft lbs @ 5100 rpm
body / frame Carbon Fiber/Kevlar/Fiberglass Panels over Steel Spaceframe
driven wheels RWD
wheel type Forged Monoblock
front tires 30/68-18
rear tires 31/71-18
steering Power-assisted rack-and-pinion
f suspension Double Wishbones w/Coil-Over-Springs, 4-Way Dampers
r suspension Double Wishbones w/Coil-Over-Springs, 4-Way Dampers
dry weight 1295 kg / 2855 lbs
weight distro 49 % / 51 %
wheelbase 2504 mm / 98.6 in
front track 1741 mm / 68.5 in
rear track 1716 mm / 67.6 in
length 4540 mm / 178.7 in
width 2050 mm / 80.7 in
height 1160 mm / 45.7 in
transmission Xtrac 6-Speed Sequential
tran clutch Multi-Disc
fuel capacity 110 litres or 29.04 gal.
