1966 Ferrari 330 P3

The 330 P3 was the next development of the 330 P2. It was almost entirely the same car as the P2 except for minor details such as the Lucas fuel injection system and ZF, 5-Speed transmission.

The P3 featured a new tubular chassis with a fibreglass tub: the engine and gearbox were an integral part of the structure, enhancing its rigidity. The engine was over 60 pounds lighter than the P2 predecessor. A large part of the weight savings was thanks to redesigned cylinder heads, and a new Lucas injection system in place of the usual battery of Weber carburettors.

In direct competition with the 330 was the Ford GT40. The Ford steamroller had placed large pressure on Ferrari the year before, and for 1966 Ford beat Ferrari at their favorite game.

At both Le Mans and Sebring of 1966 Ford GT40 outpaced and were more reliable than the 330s. These and more victories allowed Ford to claim the Manufacturers title while Porsche took the prototype class.

Ferrari 330 P3 Gallery

See full 1966 Ferrari 330 P3 Gallery here

1966 Ferrari 330 P3 1966 Ferrari 330 P3

Specs & Performance

type Racing Car
built at Modena, Italy
engine V12
position Mid Longitudinal
aspiration Natural
valvetrain DOHC 2 Valves / Cyl
fuel feed Lucas Fuel Injection
displacement 3967 cc / 242.1 in³
bore 77 mm / 3.03 in
stroke 71 mm / 2.8 in
compression 11.4:1
power 313.2 kw / 420.0 bhp @ 8000 rpm
specific output 105.87 bhp per litre
bhp/weight 583.33 bhp per tonne
driven wheels Mid Engine / RWD
front brakes Girling ventilated discs
rear brakes Girling ventilated discs
curb weight 720 kg / 1587 lbs
wheelbase 2400 mm / 94.5 in
front track 1462 mm / 57.6 in
rear track 1431 mm / 56.3 in
transmission ZF5-Speed Manual
