For the new 993 platform, Porsche heavily revised their four-wheel drive system to include a viscous coupling system that distributed power to the front and rear wheels. This made the model much smoother than the C4 it replaced.

Along with the new viscous coupler from Viscodrive, Porsche fitted a rear limited-slip differential and and automatic brake differential which applied braking force to a slipping rear wheel.

The system was vastly better than the 964’s computer controlled unit in that it added only 110 pounds to the weight of the car and had 50% less friction loss.

1994 Porsche 911 Carrera 4

Outward, the Carrera 4 was distinguished by it’s titanium-finished brake calipers, clear front turn signals and rear rear turn signals.

Story by Supercars.net

In Detail

typeSeries Production Car
built atStuttgart, Germany
body stylistTony Hatter
engineersFritz Bezner
engineM64 Flat-6
positionRear, Longitudinal
aspirationNatural
block materialAluminum Alloy
fuel feedElectronic Injection
displacement3600 cc / 219.7 in³
bore100.0 mm / 3.94 in
stroke76.4 mm / 3.01 in
power202.8 kw / 272 bhp @ 6100 rpm
specific output75.56 bhp per litre
bhp/weight188.76 bhp per tonne
torque329.5 nm / 243 ft lbs @ 5000 rpm
redline6700
body / frameUnitary Steel Monocoque w/Plastic Bumpers
driven wheels4WD
wheel typeCup Design ’93 Cast Aluminum
front tires205/50ZR17
rear tires255/40ZR17
front brakesVentilated Discs w/4-Piston Aluminum Calipers
f brake size32 x 305 mm / 1.26 x 12.01 in
rear brakesVentilated Discs w/4-Piston Aluminum Calipers
r brake size24 x 300 mm / 0.94 x 11.81 in
front wheelsF 43.2 x 17.8 cm / 17 x 7 in
rear wheelsR 43.2 x 22.9 cm / 17 x 9 in
steeringRack & Pinion
f suspensionMacPherson Struts w/Stabilizer Bar
r suspensionMulti-Link A-Arms w/Coil-Over Dampers, Stabilizer Bar
curb weight1441 kg / 3175 lbs
wheelbase2271 mm / 89.4 in
front track1445 mm / 56.9 in
rear track1473 mm / 58 in
length4244 mm / 167.1 in
width1735 mm / 68.3 in
height1316 mm / 51.8 in
transmissionType 950 6-Speed Manual
tran clutchSingle-Disc
gear ratios3.82:1, 2.05:1, 1.41:1, 1.12:1, 0.92:1, 0.78:1
final drive3.44:1
fuel capacity73.43 litres or 19.4 gal.
