2010 RK Collection Camry NASCAR Edition


2010 RK Collection Camry NASCAR Edition

2010 RK Collection Camry NASCAR Edition

The RK Collection Toyota Camry NASCAR Edition makes its public debut at the 2010 SEMA Show. The special two-door Toyota Camry NASCAR Edition was developed by RK Collection (RKC) to assist Toyota Racing Development (TRD) in visualizing the virtues of a standard Camry and morphing them into a powerful NASCAR counterpart.

The project was the visionary inspiration of Rob Kauffman, founder of RKC and co-owner of the NASCAR team Michael Waltrip Racing. The project was developed with the dual purpose of building and running a high-performance street legal Toyota Camry with a NASCAR engine. In partnership with TRD, RKC brought the concept to life with illustrations and a technical specs outline, rebuilding this one-of-a-kind high performance street machine. The vehicle was designed to showcase the technical alliance between TRD and RKC and demonstrate the connection between Toyota’s production vehicles and its strong NASCAR program.

The exterior shell of the vehicle is a RKC custom made 2010 Camry two-door body sheet metal. RKC used the body as a canvas and installed several race car features including a custom body kit, Toyota grill, carbon fiber brake ducts with fog lights and TRD emblems. The car sits on TSW Jarama wheels that measure 20 x 8.5 inches in the front and 20 x 10 in the rear and fitted with 245/35/20 Michelin Pilot tires in the front and 285/20/30 in the rear.

Underneath the exterior shell sits a powerful TRD NASCAR V8 engine that measures 358 cubic inches and delivers a blistering 680 horsepower at 8500 RPM. The engine is mated to a Tremic T-56 Magnum six-speed manual transmission with a Ram dual-disc street clutch.

Race car handling is achieved through Camry modified Macpherson struts in the front and a Venza modified multi-link independent suspension in the rear. Shocks are coil over, single adjustable.

The high performance of the NASCAR Camry can be heard through a custom three-inch exhaust with X-pipe, Thrush mufflers, Quicktime performance cut out, custom side exhaust tips and high temperature turbo Black coating by H.M. Elliot Inc.

Inside, The NASCAR Camry is modified with custom leather-covered panels, a suede headliner with integrated rear tweeters, leather-covered power seats with custom TRD billet logos, a billet shifter and a dashboard with SPEK gauges by Proparts. Comfort is enhanced with air conditioning provided by Vintage Air. For added safety a four-point roll cage was installed.

A powerful audio system was required to help offset the throaty performance under the hood. This was accomplished with a Pioneer AVIC-2110BT DVD/NAV receiver. Boston Acoustics contributed to the high-performance sound with two GT-275 75w amps, four GT-475 75w amps, two pair of SR-60 two-way 6.5 component speakers and a G212-44 12-inch subwoofer.

After its debut at the 2010 SEMA Show the RK Collection Toyota Camry NASCAR Edition can be seen during the NASCAR race weekend beginning November 12 at the Phoenix International Raceway.

In Detail

type Concept / Prototype Car
released at 2010 SEMA
engine TRD NASCAR V8
position Front, Longutidinal
displacement 5867 cc / 358 in³
bore 106.3 mm / 4.185 in
stroke 82.5 mm / 3.25 in
power 507.1 kw / 680 bhp @ 8500 rpm
specific output 115.9 bhp per litre
body / frame Custom Steel Body over Steel tube Frame
driven wheels RWD
wheel type TSW Jarama
front tires Michelin Pilot 245/35/20
rear tires Michelin Pilot 285/20/30
front brakes Wilwood Discs w/Brembo 6-piston GT Calipers
rear brakes Wilwood Discs w/Brembo 4-piston GT Calipers
front wheels F 50.8 x 21.6 cm / 20 x 8.5 in
rear wheels R 50.8 x 25.4 cm / 20 x 10 in
f suspension D2 Coil Over Struts
transmission remic T-56 Magnum 6-Speed
