2002 Pontiac Solstice Roadster Concept
The Solstic’s basic structure started life as a derivative of GM’s global small car architecture, with several modifications for structure and balance, including extensive use of aluminum.
The Solstice is powered by a rear-wheel-drive 2.2-liter DOHC supercharged EcoTec four-cylinder engine generating up to 240 horsepower with premium fuel. The supercharger is an off-the-shelf unit supplied right out of the GM Service Parts performance catalog. The engine is mated to a Borg-Warner performance six-speed manual transmission, the same one used in the Corvette.
The front end uses a simple and reliable strut configuration with a rack-and-pinion steering system derived from the Subaru WRX, one of GM’s alliance partners. The all-aluminum independent rear suspension is derived from GMs mid-size crossover SUV family and also doubles as the mount for the rear differential, which was derived from the new GM mid-size SUVs. Unique fabricated drive-shafts power the rear wheels.
In Detail
| submitted by | Richard Owen |
| engine | Ecotec L850 Inline-4 |
| aspiration | Supercharged |
| displacement | 2200 cc / 134.3 inยณ |
| power | 179.0 kw / 240.0 bhp |
| specific output | 109.09 bhp per litre |
| bhp/weight | bhp per tonne |
| torque | 305.06 nm / 225.0 ft lbs |
| driven wheels | RWD |
| front tires | Michelin Pilot 245/35R19 |
| rear tires | Michelin Pilot 255/35R20 |
| front brakes | Discs w/Power Assist |
| f brake size | mm / in |
| rear brakes | Discs w/Power Assist |
| r brake size | mm / in |
| front wheels | F 48.3 x 21.6 cm / 19.0 x 8.5 in |
| rear wheels | R 50.8 x 22.9 cm / 20.0 x 9.0 in |
| f suspension | McPherson Struts |
| r suspension | McPherson Struts |
| curb weight | 1315 kg / 2899 lbs |
| wheelbase | 2415 mm / 95.1 in |
| front track | 1532 mm / 60.3 in |
| rear track | 1537 mm / 60.5 in |
| length | 3904 mm / 153.7 in |
| width | 1805 mm / 71.1 in |
| height | 1142 mm / 45.0 in |
| transmission | GM T56 6-Speed Manual |
| gear ratios | :1 |
