2004 Porsche 911 GT3 RSR

For the upcoming racing season Porsche Motorsport presents the 911 GT3 RSR. This near-standard racing sportscar aims to keep private customer teams competitive in international Gran Turismo sport and to continue the success of the predecessor model which won its class at the Le Mans 24 Hours five times in succession, became a record and title winner in the American Le Mans Series as well as the FIA GT Championship, and secured the overall win at this year’s Daytona 24 Hour race.

Based on the new road-going 911 GT3 RS, a particularly light and sporty version of the 911 which was presented to the public at the Frankfurt Motor Show (IAA), the GT3 RSR features improvements to its predecessor in all key areas. The vehicle is available in an ACO (Automobile Club de l’Ouest) version for competing in Le Mans and in the American Le Mans Series as well as in a FIA specification.

The 911 GT3 RSR features a modified front which improves downforce at the front axle.

The 3.6-litre, six-cylinder boxer engine delivers 445 hp at 8,250 revs. Maximum torque is now 405 Nm at 7,200 rpm, with top revs reached at 8,500 (for the FIA specification with two 30.8 mm air restrictors). New pistons and rods as well as a new valve gear result in a moderate power increase with the focus on further-improved driveability and durability. A characteristic feature of the new RSR is its air-inlet which generates ram pressure.

A six speed sequential gearbox with ignition cut ensures quick gearshifts at full throttle and offers reliable protection of the gearbox from misuse.

The racing suspension, with McPherson struts in the front and the Porsche multi-link axle at the rear, features new kinematics thanks to new wheel-uprights and modified mounting points. Further improved turning in and reduced tyre wear are the most obvious results of these modifications. The double springs adjustable to four settings, the adjustable shock absorbers and anti-roll bars as well as unibal joints ensure a precise set-up to suit each circuit.

The brake system features four-piston aluminium callipers on all four wheels with discs measuring 380 mm diameter in the front and 355 mm at the rear.

Weighing 1,100 kgs (FIA specification) or 1,115 kgs (ACO spec) the 911 GT3 RSR sits at the minimum weight limit. Porsche offers various kits for different competition purposes. Porsche Motorsport will deliver the first vehicles in December.

Story by Dr. Ing. h. c. F. Porsche AG, Porsche Cars North America

In Detail

type Racing Car
built at Germany
price $ $ 279 000
engine Water Cooled, M96/70 Boxster-6 w/Dry Sump Lubrication
position Rear Longitudinal
aspiration Natural
valvetrain DOHC, 4 Valves per Cyl w/Varibale Valve Timing, Switching Intake Manifold
fuel feed Bosch Sequential Fuel Injection
displacement 3598 cc / 219.6 in³
bore 76.4 mm / 3.01 in
stroke 100 mm / 3.94 in
compression 11.7:1
power 331.8 kw / 445 bhp @ 8250 rpm
specific output 123.68 bhp per litre
bhp/weight 404.55 bhp per tonne
torque 405 nm / 298.7 ft lbs @ 7200 rpm
redline 8700
body / frame Unti Steel w/Carbon Kevlar Nose, Tail, Fenders, Doors, Truck w/Steel Roll Cage
driven wheels RWD w/Limited Slip Differential 40/60
wheel type BBS 3-Piece
front tires Front Michelin 240/640-18
rear tires Rear Michelin 270/680-18
front brakes Inner Ventilated Discs w/4-Piston Calipers
rear brakes Inner Ventilated Discs w/4-Piston Calipers
front wheels F 45.7 x 25.4 cm / 18.0 x 10 in
rear wheels R 45.7 x 27.9 cm / 18 x 11 in
steering Electric Power Steering
f suspension Fully Adjustable MacPherson Struts w/Adj Anti-Roll Bar, Adj Coil Springs, Adj Sachs Gas Shock Absorbers
r suspension Fully Adjustable Mulit-Link w/Adj Anti-Roll Bar, Adj Coil Springs, Adj Sachs Gas Shock Absorbers
curb weight 1100 kg / 2425 lbs
front track 1425 mm / 56.1 in
rear track 1496 mm / 58.9 in
length 4341 mm / 170.9 in
width 1765 mm / 69.5 in
height 1270 mm / 50 in
transmission G96/61 6-Speed Sequential w/Triple Disc Carbon Fibre Clutch
gear ratios 3.077:1, 2.13:1, 1.72:1, 1.47:1, 1.27:1, 1.12:1
