2002→2006 B.Engineering Edonis


2002→2006 B.Engineering Edonis

The B Engineering Edonis was launched in 2001 as a continuation of the Bugatti EB110 Super Sport. It was extensively re-engineered and only retained the Bugatti’s carbon-fiber chassis. Both the exterior and interior were completely redesigned and the 3.5-liter Bugatti engine was also upgraded

The Bugatti engine was increased from 3500 to 3760 cc and the four small IHI turbochargers were upgraded to two larger units from the same manufacturer. Thus, engine power increased from 449 kW (602 hp) and 650 N·m (480 lb·ft) of torque to 500 kW (670 hp) at 8000 rpm and 735 N·m (542 lb·ft).

In addition, the 4WD triple-differential drivetrain from the original Bugatti was replaced with a much simpler and lighter RWD transaxle. This saved approximately 70 kg (154 lb) from the design.

At the time of launch, B Engineering claimed a maximum speed of 365 km/h (227 mph), while accelerating from 0 to 100 km/h (62 mph) in only 3.9 seconds.

B Engineering planned to build only 21 vehicles for €760,000, but it is unlikely they reached that goal.

2002→2006 B.Engineering Edonis 2002→2006 B.Engineering Edonis 2002→2006 B.Engineering Edonis 2002→2006 B.Engineering Edonis 2002→2006 B.Engineering Edonis 2002→2006 B.Engineering Edonis 2002→2006 B.Engineering Edonis

In Detail

type Series Production Car
production years 2002 – 2006
built at Italy
price €/td> €760,000
engine 60 Degree V12
position Mid Longitudinal
aspiration Twin IHI Turbchargers
valvetrain 5 Valves per Cyl
displacement 3760 cc / 229.4 in³
power 507.1 kw / 680.0 bhp @ 8000 rpm
specific output 180.85 bhp per litre
bhp/weight 523.08 bhp per tonne
torque 735 nm / 542.1 ft lbs @ 3200 rpm
body / frame Carbon Fibre & Aluminum Chassis
driven wheels Mid Engine / RWD
front tires PAX 245/650ZR480
rear tires PAX 335/70ZR500
front brakes Inner Vented Diss w/Brembro Calipers, ABS
rear brakes Inner Vented Diss w/Brembro Calipers, ABS
f suspension Double Wishbones
r suspension Double Wishbones
curb weight 1300 kg / 2866 lbs
wheelbase 2565 mm / 101.0 in
front track 1556 mm / 61.3 in
rear track 1612 mm / 63.5 in
length 4350 mm / 171.3 in
width 1998 mm / 78.7 in
height 1120 mm / 44.1 in
transmission 6-Speed Manual
top speed ~365 kph / 226.8 mph
0 – 60 mph ~4.2 seconds
0 – 100 mph ~8.2 seconds
