Shelby American went out on a limb in 1998 and released their own car with a custom chassis and Oldsmobile L47 Aurora V8. This was the one and only Shelby product that was made from a clean slate; all previous cars having being derived from a production model.

A limited production of 250 cars had many speculating that the Series 1 might become an instant classic and one of the big opportunities of the late 1990s.

Shelby chose the 4.0-liter Oldsmobile engine to which offered 320 bhp in a car that weighed only 1,202 kg (2,650 lbs). Some of the initial prototypes were supercharged in excess of 600 bhp.

True to the Cobra’s concept, the Series One had an aluminum body with carbonfibre honeycomb panels for the floorboards. Inside the car was sparse and used widely available OEM controls and a wide range of options that included a carbon fiber dashboard, air conditioning, power windows and a GM Monsoon stereo system.

In Detail

submitted byRichard Owen
typeSeries Production Car
built atLas Vegas, USA
engineOldmobile V8
valvetrainDOHC 4 Valves / Cyl
displacement4000 cc / 244.1 in³
bore87.0 mm / 3.43 in
stroke84.0 mm / 3.31 in
compression10.3:1
power238.6 kw / 320.0 bhp @ 6500 rpm
specific output80.0 bhp per litre
bhp/weight266.22 bhp per tonne
torque393.2 nm / 290.0 ft lbs @ 5000 rpm
body / frameCarbon Fiber and Fiberglass laminate over Steel Chassis
driven wheelsFront Engine / RWD
front tiresF 265/40ZR-18 Goodyear Eagle F1
rear tiresR 315/40ZR-18 Goodyear Eagle F1
front brakesVented Discs
rear brakesVented Discs
front wheelsF 45.7 x 25.4 cm / 18.0 x 10.0 in
rear wheelsR 45.7 x 30.5 cm / 18.0 x 12.0 in
steeringRack & Pinion w/Power Assist
f suspensionDouble Wishbones w/Inboard Spring/Damper Units
r suspensionDouble Wishbones w/Inboard Spring/Damper Units
curb weight1202 kg / 2650 lbs
wheelbase2405 mm / 94.7 in
front track1509 mm / 59.4 in
rear track1534 mm / 60.4 in
length4292 mm / 168.9 in
width1943 mm / 76.5 in
height1194 mm / 47.0 in
transmission6 speed ZF trans-axle
final drive3.12:1
0 – 60 mph~4.4 seconds
0 – 100 mph~11.0 seconds
0 – 1/4 mile~12.9 seconds

Auction Sales History

1999 Shelby Series 1 5CXSA1819XL000124 – did not sell for $110,000

Low mileage. The Series 1 is the only car designed and engineered by Carroll Shelby from a clean sheet of paper and built from the ground up. All other Shelbys are re-engineered models produced by other manufacturers and modified by Shelby. Prior to production of the Series 1, significant costs were incurred in testing and certification required to conform to 1999 Federal Motor Vehicle Safety Standards. 1 of 246 production Series 1 constructed by Shelby American in 1999.

Auction Source: Kissimmee 2014, #WhereTheCarsAre by Mecum

1999 Shelby Series 1 5CXSA1810XL000173 – did not sell for $78,000 #173 of 249 manufactured. All aluminum frame. Carbon fiber body. 5-speed manual transmission. Air conditioning. Carbon fiber dash package. Speedline wheels. All power options. Very rare car. Stripe delete.
Auction Source: Kissimmee 2014, #WhereTheCarsAre by Mecum

1998 Shelby Series 1 – sold for $88,000 V8 Oldsmobile engine with 6-speed manual transmission. Only 2,370 miles. Only 250 of these cars were produced. Leather seats, cruise, tilt, power seats and power windows.
Auction Source: 2012 Barrett-Jackson Scottsdale Auction

1999 Shelby Series 1 – sold for $110,000 Number 194 of 249 built. Carbon fiber body, 2,650lbs, 4.5 sec 0-60, 185mph top speed, power steering, power brakes, air conditioning, power windows, power locks, AM/FM/CD, softtop and 6-speed transmission. 5,500 original miles.
Auction Source: 2012 Barrett-Jackson Scottsdale Auction

1999 Shelby Series I Roadster – sold for $96,250 This

This outstanding example is accented by blue racing stripes, has covered only about 3,000 miles from new and is surely one of the very best examples available today. As a very desirable late-production Series I, car number 217 of the 249 built, it also benefits from the comprehensive process and quality improvements made by Shelby American over the course of production. Desirable features include a carbon-fiber dashboard and a clear adhesive bra, which protects the front from stone chips and other minor cosmetic road damage. This Series I is offered complete with documentation including its Statement of Origin signed by Carroll Shelby, plus a letter and signed photograph from Carroll Shelby, a Series I sales brochure, a scale model and even a Shelby baseball cap.
Auction Source: 2011 Amelia Island Auction by RM Auctions
