1955 Ferrari 500 Mondial Series II


1955 Ferrari 500 Mondial Series II

1955 Ferrari 500 Mondial Series II

After producing 18 Mondials in 1953/4, Ferrari updated the design with a new engine and front suspension.

All the Series II cars had bodies by Scaglietti & C which were longer and more flowing than the Series I cars.

1955 Ferrari 500 Mondial Series II Gallery

See full 1955 Ferrari 500 Mondial Series II Gallery here

1955 Ferrari 500 Mondial Series II 1955 Ferrari 500 Mondial Series II 1955 Ferrari 500 Mondial Series II

In Detail

submitted by Richard Owen
type Racing Car
built at Maranello, Italy
body stylist Dino Ferrari
coachbuilder Scaglietti & C.
engineers Aurelio Lampredi
production 10
engine Type 111 Inline-4
position Front Longitudnal
aspiration Natural
valvetrain Gear-Driven DOHC, 2 Hairpin Valves per Cyl
fuel feed 2 Weber 45 DCOA/3 Carburetors
displacement 1985 cc / 121.1 in³
bore 90 mm / 3.54 in
stroke 78 mm / 3.07 in
compression 9.2:1
power 126.8 kw / 170.0 bhp @ 7000 rpm
specific output 85.64 bhp per litre
bhp/weight 236.11 bhp per tonne
body / frame Aluminum Panels over Tipo 510 Tubular Steel Chassis
driven wheels RWD
wheel type Borrani Wires
front tires 5.25×16
rear tires 6.00×16
front brakes Hydraulic Drums
rear brakes Hydraulic Drums
steering Worm & Wheel
f suspension Double Wishbones w/Transverse Leaf Springs, Hydraulic Dampers
r suspension De Dion Type w/Transverse Leaf Springs, Hydraulic Dampers
curb weight 720 kg / 1588 lbs
wheelbase 2248 mm / 88.5 in
front track 1276 mm / 50.2 in
rear track 1276 mm / 50.2 in
transmission Rear Mounted 5-Speed Manual
tran clutch Dry Double Plate
gear ratios 2.60:1, 1.93:1, 1.455:1, 1.098:1, 1.00:1
final drive 3.92:1
top speed ~250 kph / 155.3 mph
